coco::ihessBackwardEvaluator Class Reference

coco::ihessBackwardEvaluator::ihessBackwardEvaluator	(	std::vector< std::vector< interval > > *	__der_data,
		std::vector< std::vector< interval > > *	__hess_data,
		variable_indicator &	__v,
		const model &	__m,
		std::vector< std::vector< interval > > *	__d,
		std::vector< std::vector< interval > > *	__h,
		std::vector< interval > *	__grad,
		std::vector< interval > *	__hess
	)			`[inline]`

Definition at line 1195 of file ihess_evaluator.h.

coco::ihessBackwardEvaluator::ihessBackwardEvaluator ( const ihessBackwardEvaluator & __he ) [inline]

Definition at line 1225 of file ihess_evaluator.h.

coco::ihessBackwardEvaluator::~ihessBackwardEvaluator ( ) [inline]

Definition at line 1227 of file ihess_evaluator.h.

Member Function Documentation

int coco::ihessBackwardEvaluator::calculate ( const expression_node & __data ) [inline, virtual]

This method is called right before all children of a node are visited. The __data parameter contains the node data of the graph node being visited. The return value determines how the graph walk proceeds.

<0 perform a short-cut (the short_cut_to method will be called),

0 don't visit the children, proceed with postorder,

>0 continue with the walk by visiting the children.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1267 of file ihess_evaluator.h.

bool coco::ihessBackwardEvaluator::calculate_value ( bool eval_all ) [inline, virtual]

This method is called last for every graph node, and it produces the return value of the visitor. The parameter eval_all is true whether the node is a virtual node.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1506 of file ihess_evaluator.h.

void coco::ihessBackwardEvaluator::cleanup ( const expression_node & __data ) [inline, virtual]

The cleanup method is called just before calculate_value and should be used to clean up dynamically allocated data. The __data parameter contains the node data of the graph node being visited.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1404 of file ihess_evaluator.h.

int coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::collect	(	const node_data_type &	__data,
		const return_value &	__rval
	)			`[inline, virtual, inherited]`

This method is needed by a visitor (see VGTL documentation) and is called for each normal node everytime a child node has been visited passing the return value of the child. It is translated to a call to update.

Reimplemented from coco::_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 879 of file evaluator.h.

void coco::ihessBackwardEvaluator::initialize ( ) [inline, virtual]

This method is called at a virtual node before any children are visited.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1256 of file ihess_evaluator.h.

bool coco::ihessBackwardEvaluator::is_cached ( const node_data_type & __data ) [inline, protected, virtual]

This method checks whether the return value for this method is in the cache or can be calculated without visiting the children.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1182 of file ihess_evaluator.h.

void coco::ihessBackwardEvaluator::newPoint	(	std::vector< std::vector< interval > > *	__der_data,
		std::vector< std::vector< interval > > *	__hess_data,
		const variable_indicator &	__v
	)			`[inline]`

Definition at line 1229 of file ihess_evaluator.h.

void coco::ihessBackwardEvaluator::newResult	(	std::vector< interval > *	__grad,
		std::vector< interval > *	__hess
	)			`[inline]`

Definition at line 1239 of file ihess_evaluator.h.

void coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::postorder ( const node_data_type & __data ) [inline, virtual, inherited]

This method is needed by a visitor (see VGTL documentation) and is called right after all children of a node have been visited. It is translated into a call to cleanup.

Reimplemented from coco::_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 874 of file evaluator.h.

int coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::preorder ( const node_data_type & __data ) [inline, virtual, inherited]

This method is needed by a visitor (see VGTL documentation) and is called right before any children of a node are visited. It checks whether the result of this node is cached and calls either retrieve_from_cache and stops the downwards walk or calls calculate.

Reimplemented from coco::cached_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 862 of file evaluator.h.

virtual void coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::retrieve_from_cache ( const node_data_type & __data ) [inline, virtual, inherited]

The retrieve_from_cache method is called for retrieving the result for this node from the cache or calculate it without visiting the node's children.

Definition at line 929 of file evaluator.h.

void coco::ihessBackwardEvaluator::set_mult ( interval scal ) [inline]

Definition at line 1245 of file ihess_evaluator.h.

expression_const_walker coco::ihessBackwardEvaluator::short_cut_to ( const expression_node & __data ) [inline, virtual]

The short_cut_to method is called whenever a short-cut is signalled during the graph walk, and the const_walker returned is the target of the short-cut.

Reimplemented from coco::cached_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 1252 of file ihess_evaluator.h.

int coco::ihessBackwardEvaluator::update	(	const expression_node &	__data,
		const bool &	__rval
	)			`[inline, virtual]`

The update method is called for each virtual node everytime a child node has been visited passing the return value of the child. The __data parameter contains the node data of the graph node being visited. The return value has the following effect:

<0 stop visiting children of this node,

0 continue with the graph walk downwards the next child,

>0 skip as many children.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1452 of file ihess_evaluator.h.

int coco::ihessBackwardEvaluator::update ( const bool & __rval ) [inline, virtual]

The update method is called for each virtual node everytime a child node has been visited passing the return value of the child. The __data parameter contains the node data of the graph node being visited. The return value has the following effect:

<0 stop visiting children of this node,

0 continue with the graph walk downwards the next child,

>0 skip as many children.

Reimplemented from coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool, expression_const_walker >.

Definition at line 1442 of file ihess_evaluator.h.

return_value coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::value ( ) [inline, virtual, inherited]

This method is needed by a visitor (see VGTL documentation) and is called right before the end of the visit of a normal node to retrieve the return value. It is translated to a call to calculate_value with parameter false.

Reimplemented from coco::_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 891 of file evaluator.h.

int coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::vcollect ( const return_value & __rval ) [inline, virtual, inherited]

This method is needed by a visitor (see VGTL documentation) and is called for each virtual node everytime a child node has been visited passing the return value of the child. It is translated to a call to update.

Reimplemented from coco::_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 885 of file evaluator.h.

void coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::vinit ( ) [inline, inherited]

This method is needed by a visitor using recursive_short_cut_walk for traversing the graph. It is called before performing any graph walk when at a virtual node. It is translated to initialize.

Definition at line 900 of file evaluator.h.

return_value coco::cached_backward_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::vvalue ( ) [inline, virtual, inherited]

This method is needed by a visitor (see VGTL documentation) and is called right before the end of the visit of a virtual node to retrieve the return value. It is translated to a call to calculate_value with parameter true.

Reimplemented from coco::_evaluator_base< ihessBackwardEvaluatorType, expression_node, bool,expression_const_walker >.

Definition at line 896 of file evaluator.h.

Member Data Documentation

ihessBackwardEvaluatorType coco::_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::eval_data [protected, inherited]

The internal data of the evaluator

Definition at line 316 of file evaluator.h.

const variable_indicator* coco::cached_evaluator_base< ihessBackwardEvaluatorType , expression_node , bool , expression_const_walker >::v_ind [protected, inherited]

For caching a variable indicator is needed to check which nodes need not be re-evaluated.

Definition at line 427 of file evaluator.h.

The documentation for this class was generated from the following file:

ihess_evaluator.h


Public Types
typedef _Base::node_data_type	node_data_type
typedef _Base::return_value	return_value
typedef _Base::const_walker	const_walker
typedef ihessBackwardEvaluatorType	data_type
Public Member Functions
	ihessBackwardEvaluator (std::vector< std::vector< interval > > __der_data, std::vector< std::vector< interval > > __hess_data, variable_indicator &__v, const model &__m, std::vector< std::vector< interval > > __d, std::vector< std::vector< interval > > __h, std::vector< interval > __grad, std::vector< interval > __hess)
	ihessBackwardEvaluator (const ihessBackwardEvaluator &__he)
	~ihessBackwardEvaluator ()
void	newPoint (std::vector< std::vector< interval > > __der_data, std::vector< std::vector< interval > > __hess_data, const variable_indicator &__v)
void	newResult (std::vector< interval > __grad, std::vector< interval > __hess)
void	set_mult (interval scal)
expression_const_walker	short_cut_to (const expression_node &__data)
void	initialize ()
int	calculate (const expression_node &__data)
void	cleanup (const expression_node &__data)
int	update (const bool &__rval)
int	update (const expression_node &__data, const bool &__rval)
bool	calculate_value (bool eval_all)
int	preorder (const node_data_type &__data)
void	postorder (const node_data_type &__data)
int	collect (const node_data_type &__data, const return_value &__rval)
int	vcollect (const return_value &__rval)
return_value	value ()
return_value	vvalue ()
void	vinit ()
virtual void	retrieve_from_cache (const node_data_type &__data)
Protected Member Functions
bool	is_cached (const node_data_type &__data)
Protected Attributes
const variable_indicator *	v_ind
ihessBackwardEvaluatorType	eval_data

<0	perform a short-cut (the short_cut_to method will be called),
0	don't visit the children, proceed with postorder,
>0	continue with the walk by visiting the children.

<0	stop visiting children of this node,
0	continue with the graph walk downwards the next child,
>0	skip as many children.
